JM Model High Mechanical Strength High Speed Electric Winch 40 Ton

JM Model High Mechanical Strength High Speed Electric Winch 40 Ton

  • JM Model High Mechanical Strength High Speed Electric Winch 40 Ton
  • JM Model High Mechanical Strength High Speed Electric Winch 40 Ton
  • JM Model High Mechanical Strength High Speed Electric Winch 40 Ton
JM Model High Mechanical Strength High Speed Electric Winch 40 Ton
Product Details:
Place of Origin: China
Brand Name: Santo
Certification: ISO
Model Number: JM
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: 2999USD- 9999USD
Packaging Details: Bulk ship: Main body packaged by high quality water proof plastic woven cloths; Container: Nude for main body Spare parts are packed in high quality plywood box.
Delivery Time: 15~45 WORKING DAYS
Payment Terms: L/C, D/A, T/T
Supply Ability: 3999SETS/YEAR
Contact Now
Detailed Product Description
Product Name: Winch Place Of Origin: Henan Of China
Capacity: 5~650KN Application: Cranes, Warehouse, Industry, Workshop
Color: Customized Rope Capacity: As Your Demands
Speed: Slow Speed Or High Speed As Your Requirement
High Light:

High Mechanical Strength Electric Winch

,

High Speed Electric Winch 40 Ton

,

40T High Speed Winch

JM Model High Mechanical Strength High Speed Electric Winch 40 Ton With Good Price






Product Description:



1. High versatility, compact structure and small size.
2. Light weight, heavy lifting, easy to use and transfer.
3. As hoisting equipment, it is used for mine hoisting, well drilling and hanging (lifting) well drilling equipment, that is, lifting ore, waste (gangue) rock, lifting personnel, lowering materials, tools and equipment, etc. along the wellbore
4. As transportation equipment, it is used for underground transportation of ore (mining cart), rake ore (slag) in the stope, or filling and removing uprights.







JM Model High Mechanical Strength High Speed Electric Winch 40 Ton 0






Specification



Basic Parameters
Rated Load
Average Speed of Rope
Capacity of Rope
Rope Diameter
Hydraulic Brake
Motor Power
Overall Dimension
Total Weight
Model
KN
m/min
m
mm
Type
KW
mm
kg
JM0.5
5
16
90
7.7
TJ2-100
2.2
820X670X330
120
JM1
10
16
120
9.3
TJ2-150
5.5
830X670X330
220
JM1.5
15
16
160
11
TJ2-200
7.5
1150X900X510
310
JM2
20
16
150
12.5
TJ2-200/YWZ-200/25
7.5
1190X925X550
350
JM3
30
16
200
12.5
TJ2-200/YWZ-200/25
11
1250X1037X560
450
JM5
50
9
200
19.5
YWZ-300/45
11
1568X1300X765
1000
JM5
50
9
200
19.5
YWZ-300/45
15
1568X1350X765
1100
JM8
80
9
300
26
YWZ-300/45
15
1950X1570X1040
1800
JM8
80
15
300
26
YWZ-300/45
22
1950X1630X1040
1900
JM10
100
9
300
30
YWZ-300/45
22
2100X1700X1050
2200
JM10
100
15
300
30
YWZ-300/45
30
2100X1700X1050
2400
JM12
120
9
300
32
YWZ-300/45
22
2200X1800X1006
2500
JM16
160
9
400
36.5
YWZ-400/90
30
2330X2250X1320
4000
JM20
200
9
450
39
YWZ-400/90
45
2450X2315X1400
4500
JM30
300
9
450
47.5
YWZ-400/90
55
2600X2700X1740
7800



JM Model High Mechanical Strength High Speed Electric Winch 40 Ton 2
