20 Ton Heavy Duty Electric Winch Machine For Sale

20 Ton Heavy Duty Electric Winch Machine For Sale

  • 20 Ton Heavy Duty Electric Winch Machine For Sale
  • 20 Ton Heavy Duty Electric Winch Machine For Sale
  • 20 Ton Heavy Duty Electric Winch Machine For Sale
20 Ton Heavy Duty Electric Winch Machine For Sale
Product Details:
Place of Origin: China
Brand Name: Santo
Model Number: JM
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: 5000USD- 50000USD
Packaging Details: Bulk ship: Main body packaged by high quality water proof plastic woven cloths; Container: Nude for main body Spare parts are packed in high quality plywood box.
Delivery Time: 15~45 WORKING DAYS
Payment Terms: L/C, D/A, T/T
Supply Ability: 3500SETS/YEAR
Contact Now
Detailed Product Description
Capacity: 0.5t~50t Rope Length: 50m~500m
Structure: Electric System Brake: Hydraulic Brake System
Rated Speed: As Demands Usage: Cable Pulling Machine, Carry Heavy Goods
Color: Customized
High Light:

20Ton Electric Winch

,

VVVF Speed Electric Winch

20 Ton Heavy Duty Electric Winch Machine For Sale






Product Description:


IN CONSTRUCTION, MINE, MARINE FIELDS, OUR WINCH IS BEST CHOICE FOR YOU.

Towing, anchor, mooring, dredging, barge, dam gate winch and so on, we develop and produce winches for international customers, in most cases entirely tailored to their requirements.

Electric winch is a kind of widely using machine in lifting machinery. It can lift heavy weight in the Construction Site and Port pier, also it can be the Tractive power in installing of the factories and mines.

It not only can be used independently, but also can work with other largescale and complex machine. It has been a necessary machine in the Construction Site and Port pier.
Electric winch is made up of motor, brake, drum, wire rope, electrical appliance, base ect , which can be customized according to client requirement.



Parameter:



Items Rated load,
KN
Rated speed,
m/min
Rope capacity,
m
Rope diameter,
mm
Motor Power Size,
mm
Weight,
kg
JM1 10 15 100 9.3 Y112M-6 3 620*701*417 270
JM1.6 16 16 150 12.5 Y132M2-6 5.5 945*996*570 500
JM2 20 16 150 13 Y160M-6 7.5 945*996*570 550
JM3.2 32 9.5 150 15.5 YZR160M2-6 7.5 1430*1160*910 1100
JM3.2B 32 12 195 15.5 YZR160M2-6 7.5 1082*1014*610 536
JM5 50 10 270 21.5 YZR160L-6 11 1235*1230*805 1560
JM5B 50 9.5 200 21.5 YZR160L-6 11 1620*1260*945 1800
JM5C 50 9.5 250 21.5 YZR160L-6 11 1235*1230*805 1800
JM5D 50 15 250 21.5 YZR180L-6 15 1235*1230*805 1850
JM5E 50 20 250 21.5 YZR200L-6 22 1235*1230*805 2000
JM6 60 9.5 270 24 YZR180L-6 15 1235*1230*805 1800
JM8 80 8 250 26 YZR180L-6 15 2090*1475*956 2900
JM8B 80 9.5 350 26 YZR180L-6 15 1075*1598*985 2650



Our electric winch characteristics:

  • Reasonable structure and design hoist
  • Easy to install and Maintenance
  • High efficiency and stable performance
  • Top quality with competitive and economic price
  • Speed: Dual Speed, VVVF Speed



1591525167(winch 750).jpg



750_20200609




Our Services:



As a professional Cranes & Lifting Solutions provider, we specialize in this field over 35 years, we Santo Crane has set up a perfect sales network and after-sales service system. We have 42 sales managers and 10 engineers especially for exporting business. We believe with our rich experience, we can provide you a professional solution supporting and satisfied service.

Various special designs are available for use in particular conditions.
This is one of our particular strengths. Together with our designers, we develop a customised solution with you for your special needs.


After Order

Iso 9001:2008 Certification Used Seimens Electric Hoist

  • Delievery Time: After signing the contract and recieving the depoist, the production will take 15~25 working days as per type of products. Special standard make cost 5~10 more working days.
  • Order Tracking: After the depoist recieved, there will be a professional team tracking the order from prodction to package and shipment.
  • Crane Testing: All the materials are purchased from high quality supplier in China or the world, beyond this, we also make commissioning and test before packagement to avoid the trouble back.



After-sale Service

Iso 9001:2008 Certification Used Seimens Electric Hoist

  • Warranty Period: We provide 12 month warranty for main body. Within 12 month, there is any quality problem with the main body(not including the wearing parts), we will arrange our professional engineers to provide repairment service. Also we will provide one group wearing parts for free.

  • Installation Service: If customer don't need our engineers for installation, we will provide Remote Advisory Services. Also we could arrange engineers to provide installation service if customer need.

  • Periodic follow up for cranes serving situation. Collecting customers comment, develop better products and service.

  • Any problems come out in the usage, if that because of the quality we will take full responibility, and arrange professional after-sale department to provide solution. if that because of the misoperation or other problems, we will also provide a professional technological supporting or arrange our engineers to help if customer need.
