Name: Large Capacity Electric Double Girder Gantry Crane A5-A8 Working Duty Q235B / Q345E Materials
Brand: Santo Crane
SKU: MG MDG
Price: 9999 USD
Availability: InStock
Rating: 4.5 (166 reviews)

Home Products Double Girder Gantry Crane

Large Capacity Electric Double Girder Gantry Crane A5-A8 Working Duty Q235B / Q345E Materials

Product Details:

Place of Origin:	China
Brand Name:	Santo Crane
Certification:	ISO, CE
Model Number:	MG MDG

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	$9999-$49999
Packaging Details:	Parts packing in wooden case;Beams packing by plastic
Delivery Time:	25~45 working days
Payment Terms:	T/T,LC
Supply Ability:	1999set/year

Contact Now

Detailed Product Description

Materials:	Q235B/Q345E	Power:	Electricity
Motor:	Chinese Famous Brand/Schneider	Working Duty:	A5-A8
Control Mode:	Cab / Wireless Remote Controller	Lifting Height:	6-18m
Crane Traveling Speed:	0-45 M/min	Lifting Load:	10-75t
Power Source:	Electric	Girder Structure:	Box Type
Rated Loading Capacity:	10t, 20/5t, 32/5t, 50/10t, Or Other	Brake:	Electromagnetic Brake，Hydraulic Brake
Control Method:	Cabin Control/Remote Control	Feature:	Strong Wind Resistance
Condition:	New	Service:	Engineers Service Overseas Available
Warranty:	12 Months	Characteristic:	Customized Exported Crane
Crane Travelling Speed:	20-40m/min	Driving:	Electric Motors
High Light:	Large Capacity Double Girder Gantry Crane , Q235B/Q345E Double Girder Gantry Crane , A5-A8 Double Girder Gantry Crane

Products Description

MG double girder gantry crane is composed of bridge frame, wagon running mechanism, trolley and electrical equipment, etc.The bridge adopts box-type double-beam welding structure, and the operation mechanism of the cart is driven separately, and all the mechanisms are operated in the driver’s cab.
Note: Mostly Gantry crane is customized products,Please contact with our sales manager to make the reasonable solutions.

Double Girder Gantry Crane Components:
* Main Girder
* Flexible Leg
* Ground Beam
* Rigid Leg
* Lifting Open Winch Trolley
* Heavy Duty Trolley Festoon System
* High-strength Alloy Forged Hook
* LT Wheel Mechanism
* LT Power Supply Cable Reel Drum
* Maintenance Platform

Features:
1. Variable Frequency Drives (VFDs): Enables smooth acceleration and deceleration, reducing wear and tear on components while optimizing energy consumption.
2. Remote Control and Automation: Allows operators to control the crane remotely, enhancing safety and enabling more efficient operation.
3. Load Sensing and Anti-Sway Systems: Employ sensors and algorithms to prevent load swinging, improving load stability and operator control.
4. Collision Avoidance Systems: Integrates sensors and software to detect obstacles and prevent collisions during crane movement.

5. Energy-Efficient Components: Utilizes energy-efficient motors and components to reduce power consumption and operating costs.
6. Integrated Diagnostics and Maintenance Monitoring: Offers real-time monitoring and diagnostics to predict maintenance needs and minimize downtime.
7. Wireless Communication: Uses wireless technology for data transmission between components, enhancing flexibility and reducing cable clutter.
8. Advanced Safety Features: Includes redundant safety mechanisms, emergency stop systems, and overload protection to ensure safe operations.
9. High-strength Materials and Manufacturing: Incorporates advanced materials and manufacturing techniques to enhance structural integrity and longevity.

Safety Device:
1. Crane traveling limit switch
2. Weight overload protection system
3. Emergency stop system
4. Voltage lower protection function
5. Current overload protection system
6.Top quality long time bearing polyurethane materials buffer...

Product Paramenters

Capacity			T	50/10	75/20	100/20
Span			m	7.5~31.5
Lifting height		Main hook	m	12	20	22
		Aux.hook	m	16	22	22
Operation method				Pendent control,wireless control,cabin control
Speed	Lifting	Main hook	m/min	5.9	5.5	3.53
		Aux.hook	m/min	13.2	9.23	7.2
	Cross travel		m/min	38.5	38.4	33.86
	Long travel		m/min	74.6	65	65.6
Lifting mechanism			type	Heavy duty open winch, double girder trolley hoist
Working duty				A5,A6,A7
Power supply			AC	220/380/400/415/460V,50/60Hz, 3P

Customer Cases

Company Profile

About Santo Cranes

● Henan Santo Crane Co., Ltd, first established in 1984 was, at that time, our plants located in China Crane Hometown-Changyuan county, Henan province, covers over 510,000 square meters, have more than 10 production lines, and total assets of 8.7 million Yuan, the enterprise now boasts a staff of more than 2,500 people, including 350 people with middle or advanced professional title and more than 450 suits various kinds of manufacturing and checkout equipment. We have achieved ISO9001, ISO14001, OHSAS18000, TUV and CE certificates during the past decades. ● Santo has been a specialist in lifting, transporting, loading or unloading materials in Military Industry, Aeronautics and Astronautics, Food/Pharmaceutics, Nuclear Power/Energy, Tunnel Shields, Wind Power, Automobiles, Waste Disposal, Paper-making/Pulp, Engineering Machinery, Rail Transit, Metallurgy, Petrochemical Industry, Ships, Metal Processing, Mining, Logistics, Warehouse, Construction & Engineering and so on. ● Santo builds a complete range of overhead cranes, gantry cranes, jib cranes, port cranes, electric hoists, chain hoists, electric winch, transfer carts, boom lift, scissor lift and all crane accessories, including single girder, double girder, double leg, single leg, and cantilever styles for indoor or outdoor service. Capacities, spans and heights are virtually unlimited and customizable. ● We always aim at the decreasing of your staff cost, workshop construction cost, and highly improving the working efficiency. We work closely with clients to improve their production processes, providing solutions that are integrated, sustainable and optimised, both technically and economically. ● Our machine series combined good quality with reasonable prices. We can provide a full range of professional solution supporting and satisfied life cycle service.

Inquiry & Contact

In order to offer you a precisely quotation, please tell us these information:

1.The lifting capacity__ ton?
2.The span length is__ m? (Span=distance between center of two rails)
3.The lifting height is __m? (Lifting height=Distance from hook to ground)
4.What is the lifting speed? (Single speed or double speed)
5.What control mode do you need? (Pendant control or remote control or cabin)
6.What is the power supply in your country? (Our standard power supply is 380V,3Ph,50Hz, other pls indicate)
7.Is there any other special requirements? (If need us to supply rails? how long? etc)
