| Place of Origin: | China |
| Brand Name: | Telecrane |
| Certification: | ISO |
| Model Number: | F24-6D |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | 99USD-199USD |
| Packaging Details: | Carton Packing |
| Delivery Time: | 5-8 Working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 9999 Sets / Year |
| Product Name: | F24-6D | Material: | Plastic, Plastic And Silicone, Metal |
|---|---|---|---|
| Function: | Waterproof, LED Indicator Light, Anti Shock, Automatic, | Application: | Lifting Machinery, Crane,hydraulic Crane |
| Color: | Yellow,Black | Protection Level:: | IP65 |
| High Light: | 6 Button Wireless Crane Remote Control,IP65 Wireless Crane Remote Control,wireless crane remote IP65 |
||
F24-6D Telecrane 6 Button 2 Speed Factory Wireless Crane Remote Control Industrial Remote Control
Product Parameter
| Transmitter Parameters: F24. -TX | |
| Material | Glass-Fiber PA |
| Enclosure protection class | IP65 |
| Frequency range | VHF: 310~331 MHz; UHF: 425~446MHz |
| Transmitter power | ≤10dBm |
| Transmitter power supply | 2 AA batteries |
| Safety code | 32 bits (4.3 billion) |
| Temperature range | - 40℃~+85℃ |
| Control distance | Approx 100m (200 meters is customized) |
| Receiver Parameters: F24-RXC | |
| Material | Glass -Fiber PA |
| Enclosure protection class | IP65 |
| Frequency range | VHF: 310~331MHz; UHF: 425~446MHz |
| Receiver sensitivity | -110dBm |
| Receiver power supply | 18~65V AC/DC / 65~440V AC/DC ( optional ) |
| Output contactor capacity | 8A sealed relay output (with AC 250V/10A relays, 10A fuse) |
| Control distance | Approx 100m (200 meters is customized) |
| Safety code | 32 bits (4.3 billion) |
| Temperature range | - 40℃~+85℃ |
Features:
1. 7-12 buttons (D means double steps), STOP, START, spare buttons
2. Up to 20 control contacts
3. With battery voltage warning device, the power supply is cut off during low power
4. Safety switch key is to prevent from unauthorized user
5. Program the button function by computer interface
6. Up/down, east/west, south/north can be programmed to interlock or non-interlock
7. Power key can be programmed to start, toggle switch, normal or other functions
8. The spare buttons can be programmed to normal, interlock, toggle or start, etc
