| Place of Origin: | CHINA |
| Brand Name: | SANTO |
| Certification: | ISO, CE |
| Model Number: | CXTD |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | USD7900-79000/set |
| Packaging Details: | Electrical and other parts packed by high quality plywood crate, steel beams packed by plastic films or plastic woven cloth |
| Delivery Time: | 30-45 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2000set/year |
| Condition: | New | Span: | 7.5-31.5m |
|---|---|---|---|
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Field Installation,commissioning And Training,Online Support,Field Maintenance And Repair Service | Feature: | Bridge Crane |
| Max. Lifting Height: | 6m~30m | Motor: | ABM/SEW Brand |
| Traveling Speed: | 0-30m/min | Application: | Workshop,Warehouse,plants,factory,warehouse And So On |
| Control Method: | Remote Control, Pendant Control | Color: | Yellow, Red, Or As Requirments |
| Power Source: | 3 Phase 380V 50hz Or Be Customized | Crane Feature: | Easy Operated Girder Bridge Crane,Single Girder Overhead Crane,EOT Crane,7.5tons Overhead Crane |
| Working Class: | 1BM-5M/M3-M8 (FEM/ISO) | Lifting Mechanism: | Double Girder Electric Hoist, Open Winch Hoist Trolley |
| Lifting Speed: | Inverter Speed 0-10m/min | Main Electrical Parts: | Chint, Or As Requirments Siemens, Schneider |
| High Light: | Double Girder Overhead Crane FEM standard,CXTD Model Double Girder Overhead Crane,10 Ton Overhead Crane FEM standard |
||
Steel Coil Lifting Bridge CXTD Model 10 Ton 20 Ton 30 Ton 35 Ton Double Girder Overhead Crane
Description:
| Model No | CXTD |
| Type | European Double girder overhead crane |
| Load Capacity(t) | 1-500t |
| Lifting Height(m) | 3-35m, or customized |
| Span(m) | 7.5-31.5m,or customized |
| Travel Rail | P43,QU70-QU100 |
| Long Traveling speed | 3-30M/Min |
| Cross Traveling speed | 2--20M/Min |
| Working Class | A4-A8 |
| Origin | Henan,China |
| Power Supply | Three-phase A.C. 380V, 50Hz or customized |
| Way to control | Ground control,remote control and the combination control of two |
| Safety device | Buffer,current overload protection,overload device,power failure protection |
Features:
1. Excellent design, compact structure, light weight, low headroom
2. Flexible driving with hardened gear box
3. Stepless control smooth running
4. Real-time safety monitoring
5. Standardized features makes performance extremely stable
Crane Kits:
| 1. | Lifting motor |
Heavy duty motor 60%ED rating |
| 2. | Lifting gear box |
CrNiMo alloy harden gear(HRC60) Side hanging design |
| 3. | Lifting brake |
Double brake type available Electric magnetic brake inside Electric hydraulic thruster type with ZPMC brand |
| 4. | Wire Rope |
Reliable rope guider & anti-deflection High strength galvanized steel wire rope 2160N/mm2 Heavy blocks densely covered to avoid wire rope loosing |
| 5. | Hook Assembly |
34CrMo4QT/34CrMo6QT, Optimized size Forging hook |
| 6. | Electrical Parts |
IEC standard testing Schneider brand or as required Aviation plug no wiring connection at user’s site |
| 7. | Smart function |
2-step adjustable rotation limit switch Hook approached limit switch Grease nipples in one group Dropless latch Over speeding protection Inching / Micro-speed / Anti-sway / brake-open holding function HMI and safety monitoring system |
