| Place of Origin: | CHINA |
| Brand Name: | SANTO |
| Certification: | ISO, CE |
| Model Number: | CXTS |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | USD2000-10000/set |
| Packaging Details: | Electrical and other parts packed by high quality plywood crate, steel beams packed by plastic films or plastic woven cloth |
| Delivery Time: | 30-35 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000set/year |
| Condition: | New | Span: | 7.5-31.5m |
|---|---|---|---|
| Feature: | Bridge Crane | Max. Lifting Height: | 6m~30m |
| Max. Lifting Load: | 1-20t | Application: | Workshop,Warehouse,plants,factory,warehouse And So On |
| Control Method: | Wireless Remote Control,Ground Control,pendant Control | Rated Loading Capacity: | 1-20t |
| Color: | Yellow, Red, Or As Requirments | Power Supply: | 220V~480V 50/60Hz |
| Lifting Speed: | Inverter Speed Or Dual Speed 0~5m/min | ||
| High Light: | 16ton Workstation Bridge Crane,European Model Workstation Bridge Crane,Workshop Workstation Bridge Crane |
||
16ton European Model Workstation Bridge Crane For New Workshop Using
Description:
Europe style single Girder overhead crane is our new designed crane for the low workshop and high lifting height demands. It has many advantages such as: Strong rigidity, light dead weight, outstanding structure design, etc. It could save your factory space and investment effectively. Its technology is advanced and design is based on international standard: DIN (Germany), FEM (Europe), and ISO (International). Its particular and special travelling structure is your best choice.
Optimal Structure Designing for main box girder.
Compact Size Hoist Trolley and reasonable hook design make more space for working.
Unique Wheel Frame Design help the adjust the balance and installation. The full structure is more realizable and durable.
Motor Protect Class IP54, F class insulation. The overload protection device included.
Special designed gear box adapt helical gear, self-lubricating.
Two control ways. Pendent control panel could contact with hoist trolley or move indigently by the main girder guide. The steeples lift or travel speed could be controlled by the control panel. Remote control make operator free moving on ground. Thousands of frequency points make cranes in one workshop working without Suffering Interference.
Specification:
|
Lifting Capacity (t) |
Span (m) |
Lifting Height (m) |
Lifting Speed (m/min) |
Hoist Traveling Speed(m/min) |
Crane Traveling Speed (m/min) |
Recommended Rail Track |
| 1 | 7.5~31.5 | 6~12 | 0.8/5 | 2~20 | 3~30 | P24 |
| 2 | 6~12 | 0.8/5 | 2~20 | 3~30 | P24 | |
| 3.2 | 6~12 | 0.8/5 | 2~20 | 3~30 | P24 | |
| 5 | 6~12 | 0.8/5 | 2~20 | 3~30 | P24,P30 | |
| 10 | 6~12 | 0.8/5 | 2~20 | 3~30 | P30 | |
| 12.5 | 6~12 | 0.66/4 | 2~20 | 3~30 | P30 | |
| 16 | 9~12 | 0.66/4 | 2~20 | 3~30 | P43 | |
| 20 | 9~12 | 0.66/4 | 2~20 | 3~30 | P43 | |
| Work Duty | A5 | |||||
| Power | 380V, 50Hz or Other | |||||
| Temperature of Working Environment | ﹣20℃~﹢40℃ | |||||
| Notes: Span, lifting height is customizable as requirements | ||||||
Advantage:
1. Use imported motor with insulation grade of F and protection degree of IP54. With overheat alarm. The motor is shielded by aluminum alloy stretching cover with good heat dissipation performance;
2. Imported reducer from Germany. hardened gears with good bearing capacity, excellent seal without penetration of grease;
3. Main electric components imported from international brands such as: Siemens, Schneider and ABB etc. with protection degree not lower than IP54;
4. Wheels are forged by 65mn alloy steel with features of wear-proof, anti-fatigue and long service life.
5. Low energy consumption and maintenance free;
6. Whole crane energy saving about 30%;
7. All-in-one transmission mechanism making it work more efficient;
8. Variable frequency control whose high and low rotating speed ratio is 1:10 and work efficiency increases more than 20%;
9. Less and easy maintenance reduces the cost of maintenance;
10. Manufactured by advanced technology and constituted by high quality imported components greatly reducing malfunction and cost.
Safety Protection:
1. Locked fall-proof reducer;
2. Outdoor hoist with rain-cover;
3. Alarm indicator lights;
4. Infrared anti-collision;
Company Information:
Santo crane mainly dealing in researching, developing and producing the lifting machinery, port machinery, construction-use tower crane, reducer, etc.
The leading products of Santo widely used in Machinery, Metallurgy, Electric Power, Railway, Aerospace , Port, Petroleum, Petrochemical, etc, our products are serving the national key projects such as: the South-to-North Water Transfer Project, the West-East National Gas Transmission, the Three Gorges Hydropower Station, Jiuquan Satellite Lunching Center, Qinshan Nuclear Power Station, Hangzhou Bay Bridge, Beijing Olympic Games and so on, accelerate successfully the launch of Spacecraft Shenzhou-10 and Chang’e-3,our products have been exported to more than 69 countries like America, Japan, Russia, Korea, etc. In 2013 the annual sales revenue reached 6.669 billion, and the Overhead Traveling Crane and the Gantry Crane continue to hold the first position around the whole country.
