5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling

5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling

  • 5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling
  • 5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling
  • 5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling
5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling
Product Details:
Place of Origin: CHINA
Brand Name: SANTO
Certification: ISO, CE
Model Number: CXTS, CXTD
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD2000-10000/set
Packaging Details: Packed by high quality plywood crate
Delivery Time: 10-25 working days
Payment Terms: L/C, T/T
Supply Ability: 5000set/year
Contact Now
Detailed Product Description
Condition: New Warranty: 12 Months
Max. Lifting Load: 20t Max. Lifting Height: 3-18m
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Field Installation,commissioning And Training,Online Support,Field Maintenance And Repair Service Rated Lifting Moment: Different
Product Name: European Type Electric Hoist Application: Workshop,Warehouse,plants,factory,warehouse And So On
Control Method: Wireless Remote Control,Ground Control,pendant Control Rated Loading Capacity: 1-20t
Color: Yellow,Blue,Green, Or As Requirments Power Source: 3 Phase 380V 50hz Or Be Customized
Power Supply: 220V~480V 50/60Hz Type: Hoist Single Girder Bridge Crane,Single Girder Overhead Crane,10 Ton Overhead Crane
Lifting Mechanism: Electric Hoist Lifting Speed: 0~8m/min
Main Electrical Parts: Chint, Or As Requirments Siemens, Schneider
Highlight:

European Type Electric Wirerope Hoist

,

5000KG Electric Wirerope Hoist

,

Workshop Handling European Overhead Crane

5000 KG Good Sales Track Traveling European Type Electric Wirerope Hoist For Workshop Handling



FEM/DIN Package Monorail Electric Hoist



The electric wire rope hoist designed for single girder cranes follows the European FEM /DIN standards with compact structure, safe and efficient, easy operation. Industries use these electric wire rope hoists along with electric trolley for single girder cranes or another alternative like a fixed suspension type for applications involving goods lifting.

Electric Hoist part

Cap. Lift height Code Lift speed Lift power Travel speed Travel power Lift duty class Travel duty class H C Gauge
t m m/min KW m/min KW mm mm mm
2 6 SQ021413FBNA 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
9 SQ021413FBNB 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
12 SQ021413FBNC 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
15 SQ021413FBND 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
18 SQ021413FBNE 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
3.2 6 SQ031413FBNA 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
9 SQ031413FBNB 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
12 SQ031413FBNC 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
15 SQ031413FBND 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
18 SQ031413FBNE 5/0.8 3.2/0.45 5/20 0.37 3M/M6 2M/M5 180 556 100~250
5 6 SQ051415FENA 5/0.8 6.1/1 5/20 0.55 3M/M6 2M/M5 190 596 150~300
9 SQ051415FENB 5/0.8 6.1/1 5/20 0.55 3M/M6 2M/M5 190 596 150~300
12 SQ051415FENC 5/0.8 6.1/1 5/20 0.55 3M/M6 2M/M5 190 596 150~300
15 SQ051415FEND 5/0.8 6.1/1 5/20 0.55 3M/M6 2M/M5 190 596 150~300
18 SQ051415FENE 5/0.8 6.1/1 5/20 0.55 3M/M6 2M/M5 190 596 150~300
6.3 6 SQ061415FENA 5/0.8 6.1/1 5/20 0.55 1Am/M4 2M/M5 190 556 150~300
9 SQ061415FENB 5/0.8 6.1/1 5/20 0.55 1Am/M4 2M/M5 190 556 150~300
12 SQ061415FENC 5/0.8 6.1/1 5/20 0.55 1Am/M4 2M/M5 190 556 150~300
15 SQ061415FEND 5/0.8 6.1/1 5/20 0.55 1Am/M4 2M/M5 190 556 150~300
18 SQ061415FENE 5/0.8 6.1/1 5/20 0.55 1Am/M4 2M/M5 190 556 150~300
8 6 SQ082411FHNA 5/0.8 9.5/1.5 5/20 0.75 3M/M6 2M/M5 200 1150 150~300
9 SQ082411FHNB 5/0.8 9.5/1.5 5/20 0.75 3M/M6 2M/M5 200 1150 150~300
12 SQ082411FHNC 5/0.8 9.5/1.5 5/20 0.75 3M/M6 2M/M5 200 1150 150~300
15 SQ082411FHND 5/0.8 9.5/1.5 5/20 0.75 3M/M6 2M/M5 200 1150 150~300
18 SQ082411FHNE 5/0.8 9.5/1.5 5/20 0.75 3M/M6 2M/M5 200 1150 150~300
10 6 SQ102411FHNA 5/0.8 9.5/1.5 5/20 0.75 2M/M5 2M/M5 200 1150 150~300
9 SQ102411FHNB 5/0.8 9.5/1.5 5/20 0.75 2M/M5 2M/M5 200 1150 150~300
12 SQ102411FHNC 5/0.8 9.5/1.5 5/20 0.75 2M/M5 2M/M5 200 1150 150~300
15 SQ102411FHND 5/0.8 9.5/1.5 5/20 0.75 2M/M5 2M/M5 200 1150 150~300
18 SQ102411FHNE 5/0.8 9.5/1.5 5/20 0.75 2M/M5 2M/M5 200 1150 150~300
12.5 6 SQ122411FJNA 4/0.6 12.5/2 5/20 0.75 1Am/M4 2M/M5 200 1150 150~300
9 SQ122411FJNB 4/0.6 12.5/2 5/20 0.75 1Am/M4 2M/M5 200 1150 150~300
12 SQ122411FJNC 4/0.6 12.5/2 5/20 0.75 1Am/M4 2M/M5 200 1150 150~300
15 SQ122411FJND 4/0.6 12.5/2 5/20 0.75 1Am/M4 2M/M5 200 1150 150~300
18 SQ122411FJNE 4/0.6 12.5/2 5/20 0.75 1Am/M4 2M/M5 200 1150 250~350
16 6 SQ163412EKNA 4/0.6 16/2.6 5/20 0.75*2 2M/M5 2M/M5 250 1320 250~350
9 SQ163412EKNA 4/0.6 16/2.6 5/20 0.75*2 2M/M5 2M/M5 250 1320 250~350
12 SQ163412EKNA 4/0.6 16/2.6 5/20 0.75*2 2M/M5 2M/M5 250 1320 250~350
15 SQ163412EKNA 4/0.6 16/2.6 5/20 0.75*2 2M/M5 2M/M5 250 1320 250~350
18 SQ163412EKNA 4/0.6 16/2.6 5/20 0.75*2 2M/M5 2M/M5 250 1320 250~350
20 6 SQ204412EKLA 4/0.6 16/2.6 5/20 0.75*2 1Am/M4 2M/M5 250 1320 250~350
9 SQ204412EKLB 4/0.6 16/2.6 5/20 0.75*2 1Am/M4 2M/M5 250 1320 250~350
12 SQ204412EKLC 4/0.6 16/2.6 5/20 0.75*2 1Am/M4 2M/M5 250 1320 250~350
15 SQ204412EKLD 4/0.6 16/2.6 5/20 0.75*2 1Am/M4 2M/M5 250 1320 250~350
18 SQ204412EKLE 4/0.6 16/2.6 5/20 0.75*2 1Am/M4 2M/M5 250 1320 250~350
- Loading capacity: 1.25 ~ 20t
- Lifting height: 6 ~ 18m
- Lifting speed Double speed: 0.8/5 m/min; or customized
- Traveling speed Variable frequency speed: 2 ~ 20 m/min; or customized
- Working class: M5 / M6 (FEM 2M/3M)
- Working temperature: -20 ~ 40 ℃
- Power supply: AC-3Phase-220//230/380/400/415/440V-50/60Hz
- Control voltage: DC-36 / 48V

The electric wire rope hoist designed for single girder cranes follows the European FEM /DIN standards with compact structure, safe and efficient, easy operation. Industries use these electric wire rope hoists along with electric trolley for single girder cranes or another alternative like a fixed suspension type for applications involving goods lifting.



5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling 0

5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling 1

5000 KG Track Traveling European Type Electric Wirerope Hoist For Workshop Handling 2
