Advanced Single Beam Overhead Crane With Pendant / Wireless Remote Control

Advanced Single Beam Overhead Crane With Pendant / Wireless Remote Control

  • Advanced Single Beam Overhead Crane With Pendant / Wireless Remote Control
  • Advanced Single Beam Overhead Crane With Pendant / Wireless Remote Control
Advanced Single Beam Overhead Crane With Pendant / Wireless Remote Control
Product Details:
Place of Origin: China
Brand Name: Santo Crane
Certification: ISO, CE
Model Number: LD
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: $4999-49999
Packaging Details: Parts packing in wooden case;Beams packing by plastic
Delivery Time: 10~30 working days
Payment Terms: T/T,LC,Western Union
Supply Ability: 2999set/year
Contact Now
Detailed Product Description
Crane Traveling Speed: 20m/min Lifting Speed: 3-8m/min
Optional Device: Rain Cover/Weight Display/Lighting System Feature: Overhead Crane
Lifting Height: 6-30m Trolley Traveling Speed: 20m/min
Control Method: Pendant Control + Wireless Remote Control Ambient Temperature: -20℃~+40℃
High Light:

Wireless Remote Control Overhead Crane

,

Single Beam Overhead Crane

,

Wireless Remote Control Beam Overhead Crane

Product Description:




Single Girder Overhead Crane is a high-performance solution that combines speed, power, and precision. It is specifically tailored to meet the needs of businesses that require efficient and reliable lifting capabilities within their operations. Whether it is referred to as a Single Girder Overhead Crane or a Single-Beam Overhead Crane, this product is synonymous with quality and performance, offering unparalleled value to its users.

Advanced Single Beam Overhead Crane With Pendant / Wireless Remote Control 0



Features:

  • Product Name: Single Girder Overhead Crane
  • Lifting Speed: 3-8m/min
  • Feature: Overhead Crane
  • Rail Type: P18/P24/P38/P43/P50
  • Lifting Height: 6-30m
  • Crane Traveling Speed: 20m/min
  • Also known as: Single Girder Bridge Crane
  • Alternative name: Single-Beam Overhead Crane


Technical Parameters:

Parameter Specification
Span 7.5-31.5m
Optional Device Rain Cover/Weight Display/Lighting System
Trolley Traveling Speed 20m/min
Lifting Speed 3-8m/min
Control Method Pendant Control + Wireless Remote Control
Crane Traveling Speed 20m/min
Safety Device Overload Limiter/Limit Switch/Buffer
Working Class A3-A5
Rail Installation Ceiling Mounted
Rail Type P18/P24/P38/P43/P50



Advanced Single Beam Overhead Crane With Pendant / Wireless Remote Control 1Advanced Single Beam Overhead Crane With Pendant / Wireless Remote Control 2




Q1: What is the brand and model number of the Single Girder Overhead Crane?

A1: The brand of the Single Girder Overhead Crane is Santo Crane, and the model number is LD.

Q2: Where is the Santo Crane Single Girder Overhead Crane manufactured?

A2: The Santo Crane Single Girder Overhead Crane is manufactured in China.

Q3: What certifications does the Santo Crane Single Girder Overhead Crane come with?

A3: The Santo Crane Single Girder Overhead Crane comes with ISO and CE certifications.

Q4: What is the price range for the Santo Crane Single Girder Overhead Crane?

A4: The price range for the Santo Crane Single Girder Overhead Crane is between $4999 to $49999.

Q5: What are the delivery time and payment terms for purchasing the Santo Crane Single Girder Overhead Crane?

A5: The delivery time for the Santo Crane Single Girder Overhead Crane is 10 to 30 working days. The payment terms are T/T, LC, or Western Union.
