| Place of Origin: | China |
| Brand Name: | Santo Crane |
| Certification: | ISO, CE |
| Model Number: | LX |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | $499-49999 |
| Packaging Details: | Parts packing in wooden case;Beams packing by plastic |
| Delivery Time: | 10~30 working days |
| Payment Terms: | T/T,LC,Western Union |
| Supply Ability: | 2999set/year |
| Rail Installation: | Ceiling Mounted | Rail Type: | P18/P24/P38 |
|---|---|---|---|
| Ambient Temperature: | -20℃~+40℃ | Optional Device: | Rain Cover/Weight Display/Lighting System |
| Control Method: | Remote Control | Power Supply: | 3-Phase AC 220V/380V/400V/415V 50/60Hz |
| Lifting Capacity: | 1-20t | Lifting Height: | 6-30m |
| Lifting Speed: | 0.3-8m/min | Material Of Girder: | Q235B/Q345B |
| Product Name: | Single Girder Overhead Crane | Span Length: | 7.5-31.5m |
| Travelling Speed: | 20m/min | Working Class: | A3-A5 |
| High Light: | 20t single girder overhead crane,single girder overhead crane ceiling mounted,remote control single girder bridge crane |
||
* LX model single girder overhead crane is characterized by more reasonable structure and higher strength steel as a whole.
* Used together with CD1 model MD1 model electric hoist as a complete set, it is a light duty crane with a capacity 1 ton ~ 32 tons. The span is 7.5m~ 31.5m. Working grade is A3~A4.
* This product is widely used in plants, warehouse, material stocks to lift goods. It is prohibited to use the equipment in the combustible, explosive or corrosive environment.
* This product has two operational methods, ground or operational room which has open model closed model and can be installed on the left or right side according to the practical situation.
* And the direction of entering the gate has two forms, sideway and ends in order to satisfy the users, choice under different conditions.
1. Heavy Duty and High Efficient;
2. Suitable for any environment ( High Temperature, Explosion Proof and so on);
3. Long Life Span: 30-50years;
4. Easy for Installation and maintenance;
5. Reasonable structure and strong rigidity;
6. The speed can be frequency inverter speed control;
7. Control method is cabin control or remote control;
8. Depending on lifting cargo, crane can be equipped with hanging beam magnet or magnet chuck or Grab or C hook;
9. Crane is equipped with all moving limit switch, loading limit and other standard safety devices, to promise crane work safe.
Santo Crane, a leading brand of Single Girder Bridge Crane, Single-Beam Overhead Crane and Single-Beam Overhead Crane with Hook, is proudly made in China and certified by ISO and CE. The minimum order quantity is 1 set and the price range is from $499 to 49999. The crane is packed in parts in wooden cases and beams in plastics, and is delivered within 10 to 30 working days. The payment terms are T/T, LC, and Western Union. The supply ability is 2999 sets per year. It is built with safety devices such as overload limiter, limit switch and buffer. The traveling speed is 20m/min and the ambient temperature is -20℃~+40℃. Optional devices include rain cover, weight display and lighting system. It is designed to work in A3-A5 class environment.
Packaging and Shipping of Single Girder Overhead Crane
