Keywords: | Bridge Gantry Cranes | Load Capacity: | 20 T To 900 T |
---|---|---|---|
Span: | 6 M - 50 M | Max.Lifting Height: | 18m |
Structurte: | Truss Structure Type | Control Mode: | Remote |
Power Supply: | Diesel Generating Set /380v-50hz,3Phase A.C | Image Design: | Classic Design (Ruby Red, Ruby Blue, White) |
High Light: | 42M Span Trussed Type Gantry Crane,75ton Trussed Type Gantry Crane,Shipyard Construction Crane Equipment |
Information:
Bridge gantry cranes are gantry cranes specially designed for bridge construction. The lattice girder gantry crane is mainly composed of main girder, outriggers, bridge crowns, etc. The components are connected by pins and high-strength bolts, which are convenient for disassembly, equipment and transportation; compared with ordinary gantry cranes, installation is fast, convenient and economical practical.
As a type of gantry crane, it is a special crane designed for bridge construction. It is composed of main girder, outriggers, bridge crane, etc. All parts are connected by high-strength friction clamping bolts and hinge pins, which are convenient for disassembly and transportation. Compared with ordinary gantry cranes, it is convenient and quick to install, economical and practical. Commonly used in mobile road and bridge construction units.
Specification:
1. Load capacity: 20 t to 900 t
2. Span: 6 m - 50 m
3. Max.Lifting Height: 18m
4. Structurte: Box / truss structure type
6. Character: Single girder/Double griders
7. Power Supply : Diesel generating set /380v-50hz,3Phase A.C
8. Grade ability: 1%-2%
9. Control mode: Remote/Cabin control
10 Running mode:Straight/across/diagonal
11. Image Design: Classic design (Ruby red, ruby blue, white)
Capacity | t | 10 | 16/3.2 | 20/5 | 30/10 | 36/10 | 50/10 | |
Span | m | 18,22,26,30,35 | ||||||
Lifting height | Main | m | 10-12 | 10 | 10-12 | 10-12 | 10-12 |
10-12 |
Aux | m | 11.7-12.7 | 10.6-12.6 | 10.7-12.7 | 11-13 | 11.28-13.28 | ||
Working duty | A5-A7 | |||||||
Speed |
Main hoisting |
m/min | 18.4 | 13 | 9.2 | 10.4 | 7.7 |
6 |
Aux.hoisting | 18.4 | 18.4 | 13.2 | 8 | ||||
Trolley traveling speed | 43.8 | 41.9 | 42.3 | 42 | 39.1 | 38.13 | ||
Crane traveling speed | 48.4-54.6 | 48-53 | 40.1 | 51.2 | 40 | 43.8 | ||
Installed power | KW | 58-66 | 85-93 | 86-94 | 131-138 | 132-140 |
197-213 |
|
Max. weheel load | KN | 299-423 | 198-265 | 218-299 | 292-350 | 334-427 | 270-456 | |
Recommend rail | QU80 | QU70 | QU70 | QU80 | QU80 | QU80/QU70 | ||
Power supply | 380V-50HZ,3Phase A.C |
Application:
It is suitable for frequently flowing road and bridge construction units. Mainly suitable for moving concrete bridges, precast slabs, precast slabs from one place to another. This gantry crane is divided into two types: one is track type and the other is tire type.
