Fixed Column 8m Length Cantilever Arm Jib Crane Free Standing 3.2 Ton

Fixed Column 8m Length Cantilever Arm Jib Crane Free Standing 3.2 Ton

  • Fixed Column 8m Length Cantilever Arm Jib Crane Free Standing 3.2 Ton
  • Fixed Column 8m Length Cantilever Arm Jib Crane Free Standing 3.2 Ton
  • Fixed Column 8m Length Cantilever Arm Jib Crane Free Standing 3.2 Ton
Fixed Column 8m Length Cantilever Arm Jib Crane Free Standing 3.2 Ton
Product Details:
Place of Origin: CHINA
Brand Name: SANTO
Certification: ISO, CE
Model Number: BXB, BZZ, BXD, BXN, BZD, BZN
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD3000-5000/set
Packaging Details: Electrical and other parts packed by high quality plywood crate, steel beams packed by plastic films or plastic woven cloth
Delivery Time: 15-30 working days
Payment Terms: L/C, T/T
Supply Ability: 5000set/year
Contact Now
Detailed Product Description
Condition: New Warranty: 12 Months
Arm Outreach: 3-20m After-sales Service Provided: Engineers Available To Service Machinery Overseas,Field Installation,commissioning And Training,Online Support,Field Maintenance And Repair Service
Feature: Jib Crane Max. Lifting Height: 6m~30m
Rated Lifting Moment: Different Max. Lifting Load: 20t
Product Name: Jib Crane Application: Workshop,Warehouse,plants,factory,warehouse And So On
Control Method: Wireless Remote Control,pendant Control Rated Loading Capacity: 1-20t
Color: Yellow, Red, Or As Requirments Power Source: 3 Phase 380V 50hz Or Be Customized
Power Supply: 220V~480V 50/60Hz Crane Feature: Easy Operated Jib Crane
Type: Slewing Arm Jib Crane, Light Crane System Lifting Mechanism: Electric Hoist, Chain Hoist, Chain Block, Etc
Lifting Speed: 0~8m/min Main Electrical Parts: Chint, Or As Requirments Siemens, Schneider
High Light:

8m Length Cantilever Arm Jib Crane

,

Freestanding Jib Crane 3.2 Ton

,

Fixed Column Jib Crane

Fixed Column Free Standing 8m Length Cantilever Arm Jib Crane 3.2 Ton In Workstations




Description:



Jib crane is also called jib crane. It is a small and medium-sized lifting equipment developed in recent years. It has a unique structure, is safe and reliable, has the characteristics of high efficiency, energy saving, time saving and labor saving, and flexibility. In the case of intensive transportation, it shows its superiority compared with other conventional lifting equipment. Widely used in various places in various industries.



Features:



(1) Simple installation

Wall traveling jib cranes can be mounted on wall, no special floor space required.



(2) Shorten loading time, improve work efficiency

With a jib crane, workers can lift, quickly transport and precisely deposit all kinds of work pieces at any time.



(3) Easy handing, lighten laboring work

It can relieve the strain of physically demanding work on your staff. The risk of injuries or accidents when handing heavy or unwieldy parts is considerably reduced.



(4) High quality with good price

All of our cranes are ending with full load factory testing of every part, certifies the functionality and quality to customers. We will offer you the most adequate equipments for your needs through good communication.



Technical parameters:



Model Lift Capacity(t) Arm Length(mm)
BXB0.25 0.25 10000
BXB0.5 0.5
BXB1 1 10000
BXB2 2 10000
BXB3 3 7500
BXB5 5 6500









Main Classification of Jib Crane:



We have three models: Free Standing Jib Crane, Wall Mounted Jib Crane and Wall Traveling Jib Crane.



Fixed Column 8m Length Cantilever Arm Jib Crane Free Standing 3.2 Ton 0



Safe operation:


When operating a jib crane, all national safety technical regulations for the use and operation of the crane should be followed. For your safety and to avoid damage to the equipment, please observe the following safety practices.



  • The use of jib cranes to transport people is not permitted.
  • Do not lift loads over personnel. Do not pull or tow loads.
  • Overloading is not allowed.
  • Avoid hitting the limit switch with the lifting hook during normal operation.



Application:



Widely applied in professions and so on machinery, metallurgy, automobile, shipbuilding, glass, papermaking, chemical industry.

When looking for a lifting option for a smaller space, one should look to the option for Jib Crane. This crane is an excellent choice, as it is strong and versatile, robust and flexible. The tough construction of the jib boom ensures that it will not wear out. These cranes can be used for material and machinery loading-unloading small assembly jobs, localized fitting etc.



Fixed Column 8m Length Cantilever Arm Jib Crane Free Standing 3.2 Ton 1
