Heavy Duty 75ton Double Beam Gantry Crane For Stock Yard

Heavy Duty 75ton Double Beam Gantry Crane For Stock Yard
Heavy Duty 75ton Double Beam Gantry Crane For Stock Yard

Large Image :  Heavy Duty 75ton Double Beam Gantry Crane For Stock Yard

Product Details:

Place of Origin: CHINA
Brand Name: SANTO
Certification: ISO, CE
Model Number: MG

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: USD6000-40000/set
Packaging Details: Electrical and other parts packed by high quality plywood crate, steel beams packed by plastic films or plastic woven cloth
Delivery Time: 35-45 working days
Payment Terms: L/C, T/T
Supply Ability: 5000set/year
Detailed Product Description
Condition: New Span: 7-35m
Feature: Gantry Crane Max. Lifting Height: 6m~30m
Product Name: Rail Mounted Gantry Crane Application: Workshop,Warehouse,plants,factory,warehouse And So On
Color: Yellow, Red, Or As Requirments Power Source: 3 Phase 380V 50hz Or Be Customized
Crane Feature: Easy Operated Gantry Crane, Portal Crane, Goliath Crane Type: Heavy Duty Double Girder Gantry Crane
Lifting Mechanism: Open Winch Trolley Lifting Speed: Standard Or As Requirement
Main Electrical Parts: Chint, Or As Requirments Siemens, Schneider
High Light:

75ton Double Beam Gantry Crane

,

Heavy Duty Double Beam Gantry Crane

,

Gantry Crane For Stock Yard

Heavy Duty 75ton Double Beam Gantry Crane For Stock Yard




General description:



Double girder gantry crane with hook is applied outside warehouse or railway sideways to do common lifting and unloading works.

This kind of crane is composed of bridge, supporting legs, crane travelling mechanism, trolley with strong lifting winch, electric equipment and control system.

As its heavy duty design, it can be widely used in all kinds of industrial field. As its heavy duty design, it can be widely used in all kinds of industrial field.



Heavy Duty 75ton Double Beam Gantry Crane For Stock Yard 0

Technical Parameters:



Capacity (ton) 5 10 16/3.2 20/5 32/5 50/10
Span (m) 18, 22, 24, 26, 30, 35
Lifting height (m) 10, 11, 12
Working class A5
Control way Cabin control or remote control
Power source 380V 50HZ 3phase (Could supply it as yours)
Trolley lifting mechanism

Lifting speed

(m/min)

Main hook 11.3 8.5 7.9 7.2 7.5 5.9
Auxiliary hook - - 14.6 15.4 15.4 10.4
Trolley traveling mechanism
Traveling speed (m/min) 37.3 35.6 36.6 36.6 37 36
Crane traveling mechanism
Traveling speed (m/min) 37.3 39.7 37.3 39.7 39.4 38.5
Motor power(KW) 40.8-51.8 41.5-52.8 80-77 84-81 99.3-117.3 126.5
Rail track recommended 43kg/m 43kg/m or QU70



Mechanical feature:

1. Double welding box girder, DIN/FEM standard deflection

2. Steel tube legs, high strength, and small size

3. 10.9 class High tension bolts mounting between girder and end beams.

Ensure the whole machine structure strong and precise

4. Vertical gear motor of three-in-one driving, more safety and smaller space

5. Long travel high protection class IP55, F class, 40% ED

6. End carriage equipped with anti-friction bearings, crane buffer block, derailment protectors.



Double girder ganty crane series:



MG double girder box type gantry crane

· Loading capacity:5~800T

· Lifting height:6~30m

· Span:5~35M

· Working calss:A5~A7

· Power supply:220 ~ 440V,50/60Hz,3Phase

· Working temperature:-20-40 ℃





MG double girder truss type gantry crane

· Loading capacity:5~800T

· Lifting height:6~30m

· Span:18~35m

· Working calss:A5~A7

· Power supply:220 ~ 440V,50/60Hz,3Phase

· Working temperature:-20-40 ℃



U type double girder gantry crane

· Loading capacity:5~800T

· Lifting height:6~30m

· Span:18~35m

· Working calss: A5~A7

· Power supply:220 ~ 440V,50/60Hz,3Phase

· Working temperature:-20-40 ℃





MZ double girder gantry crane with grab bucket

· Loading capacity:5~100T

· Lifting height:6~30m

· Span:18~35m

· Working calss:A5~A7

· Power supply:220 ~ 440V,50/60Hz,3Phase

· Working temperature:-20-40 ℃





Double girder semi gantry crane

· Loading capacity:5~32T

· Lifting height:6~30m

· Span:6~35m

· Working calss: A3~A5

· Power supply:220 ~ 440V,50/60Hz,3Phase

· Working temperature:-20-40 ℃



Heavy Duty 75ton Double Beam Gantry Crane For Stock Yard 1
